W29GL032C
8
8.1
ELECTRICAL CHARACTERISTICS
Absolute Maximum Stress Ratings
Surrounding Temperature with Bias
Storage Temperature
V CC Voltage Range
E VIO Voltage Range
A9, #WP/ACC Voltage Range
Other Pins Voltage Range
Output Short Circuit Current (less than one second)
-65°C to +125°C
-65°C to +150°C
-0.5V to +4.0V
-0.5V to +4.0V
-0.5V to +10.5V
-0.5V to V CC +0.5V
200 mA
Table 8-1
Absolute Maximum Stress Ratings
8.2
Operating Temperature and Voltage
Industrial Grade Surrounding Temperature (TA)
Full V CC Range Supply Voltage
Regulated V CC Range Supply Voltage
E VIO Range Supply Voltage (1)
-40°C to +85°C
+2.7V to 3.6V
+3.0V to 3.6V
1.65V to V CC
Table 8-2
NOTE:
Operating Temperature and Voltage
1.
2.
3.
4.
The EVIO feature was designed to support voltages from 1.65V to VCC. Device testing is conducted at EVIO=VCC.
Stresses greater than those listed under ABSOLUTE MAXIMUM RATINGS may cause permanent damage to the
device. This is stress rating only and functional operational sections of this specification are not implied. Exposure to
absolute maximum rating conditions for extended period may affect reliability.
Specifications contained within the following tables are subject to change.
During voltage transitions, all pins may overshoot VSS to -2.0V and VCC to +2.0V for periods up to 20ns, see below
Figure.
Vss
20ns
20ns
20ns
Vcc +2.0V
Vss -2.0V
Vcc
20ns
20ns
20ns
Figure 8-1
Maximum Negative Overshoot Figure 8-2
Maximum Positive Overshoot
Publication Release Date: August 2, 2013
29
Revision H
